High-Efficiency Flow Junction: Provides a precision-moulded 90° junction to join a lateral pipeline into a main twinwall carrier or land drainage run.
Triple Socket Design: Features three captive socketed ends for fast, secure push-fit connections directly onto twinwall pipe lengths without requiring external couplers.
Lightweight & High Strength: Manufactured from high-density polyethylene (HDPE) for exceptional structural rigidity against soil loads and backfill impact.
Corrosion & Chemical Resistant: Immune to aggressive ground chemicals, subsoil acids, and biological degradation for a long service life.
Multiple Size Options Available: Fully compatible with Brett Martin surface water and agricultural drainage systems in 110mm, 150mm, and 225mm diameters.
The Brett Martin 90° Twinwall Triple Socket Branch is an essential pipe fitting engineered for non-pressure surface water management, highway drainage, and agricultural land drainage applications. Designed to create a clean, 90-degree lateral connection into a main carrier line, this fitting ensures maximum hydraulic efficiency while maintaining optimal flow rates.
Built with three integrated spigot sockets, the branch eliminates the need for separate couplers, significantly speeding up installation times on site. When used with compatible sealing rings, it provides a watertight seal that prevents silt ingress and root penetration. Manufactured from robust HDPE, this fitting combines lightweight maneuverability for groundworkers with high ring stiffness to withstand heavy backfill pressure and traffic loading.
Feature
Specification
Brand
Brett Martin
Product Type
Twinwall 90° Triple Socket Branch / Tee
Product Codes
1TT90 (110mm) / 2TT90 (150mm) / 3TT90 (225mm)
Nominal Diameters
110mm / 150mm / 225mm
Material
High-Density Polyethylene (HDPE)
Angle
90°
Joint Type
Triple Push-Fit Sockets
Application
Surface Water, Civil Engineering & Agricultural Land Drainage
Code:
